AFDM Auto Focusing Macro Zoom Camerais a series of electric controlled continuous zoom and autofocus all-in-one digital microscope with a large field of view.
It is integrated with HDMI/USB/ETH/WiFi camera, Electric Controlled Continuous Zoom Auto-focus Objective and LED Integrated Illumintaion Light (optional)
AFDM412 supports HDMI/USB/ETH/WiFi control and video output (ToupView). The frame rate of the output is 4K/30FPS, and the zoom range is 1X~18X giving 255 x 145mm at 1x and 14.2 x 8mm at 18x with a working distance 205-255mm
Auto Focusing Macro Zoom Camera
£995.00Price
Excluding Sales Tax
Ideal for
Technical Specification
- 5 groups 16 elements EMZO with 0.0218~0.392X, 18 zoom ratio, supports auto and manual focus
- 250mmstandard working distance with 205~255mm depth of field
- At standard working distance, the large field of view 255mm*145mm at low magnification, helping users to quickly locate the target object, the small field of view 12mm*8mm at higher magnification, helping users to observe microscopically
- Sony 1/2.8” 4K Starvis CMOS with high signal-to-noise ratio
- 4K HDMI/USB/ETH/WiFi multiple video outputs
- 4K/1080P auto switching according to monitor resolution
- SD card/USB flash drivefor captured image and video storage, support local preview and playback
- Built-in mouse control software XFCAMView,all functions can be realized with USB mouse
- Embedded mouse Camera Control Panel, Measurement Toolbar, Synthesis Control Toolbar, AF Control Panel
- Multi-language support
- Head suction LED ring light, the brightness can be directly controlled by XFCAMView
- With the adapter bracket of 76mm diameter, a electric controlled continuous zoom AFDM can be built
